| AXI 22 AT D Plus |
Available now, the Extron AXI 22 AT D Plus, is a single-gang decorator-style Dante® audio interface for integrating two mic/line sources onto a Dante-enabled audio system. It features two XLR audio inputs and switchable 48 volt phantom power for connecting and powering condenser microphones, plus gain control via the network for each input. The AXI 22 AT D Plus also features two line outputs for routing any two Dante channels from the network to the analog input of a destination device, or connecting into an optional secondary wallplate with two XLR outputs. The AXI 22 AT D Plus interfaces with any Dante-equipped audio processor, such as an Extron DMP 128 Plus AT, over a standard local area network, and can be powered through PoE. This allows a single network cable connection for bidirectional audio, control, and power from a central equipment rack.
The AXI 22 AT D Plus joins the popular AXI Series Dante Audio Interfaces from Extron, which include the AXI 22 AT, AXI 44 AT, and AXI 02 AT.
Key Features
- Two mic/line inputs on XLR connectors insert audio onto a Dante network
- Two line outputs on a rear panel captive screw connector extract audio from a Dante network
- Dante audio networking provides a wide range of expansion capabilities
- Controlled with DSP Configuration Software or via SIS from a DMP Plus Series processor on the Dante network or a control processor
- Studio grade 24-bit analog-to-digital and digital-to-analog converters
selectable up to 96 kHz - Includes black and white faceplates
- Compatible with Extron WPD 100 Series wallplates
| AXI 22 AT D Plus | ||
|---|---|---|
| MODEL | VERSION DESCRIPTION | PART # |
| AXI 22 AT D Plus | 2×2 Dante Audio Interface, Decorator Style | 60-1947-01 |
| AXI 22 AT D PLUS & WPD 102 XLRM | AXI 22 AT D Plus & WPD 102 XLRM Kit – Black | 60-1942-22 |
| AXI 22 AT D PLUS & WPD 102 XLRM | AXI 22 AT D Plus & WPD 102 XLRM Kit – White | 60-1942-23 |
Feel free to email or call us to purchase this Product.
